CLIMB, CORNER AND DESCEND WITH GREATER SPEED, MORE CONTROL AND MAXIMUM EFFICIENCY. FROM THE MOUNTAINS TO THE FLATS, IN ALL CONDITIONS, THIS LIGHTWEIGHT COMPOSITE ROAD RACER TAKES YOU TO THE NEXT LEVEL.
KEY PERFORMANCE FACTORS
Class-leading efficiency
Combining best-in-class stiffness-to-weight with strategically placed aero tube shaping, this frameset is engineered for faster climbing, explosive acceleration and unyielding pedaling stiffness for race-winning performance.
Advanced aerodynamics
This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.
Total control
Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mount brakes and thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tyres up to 32mm.
Components
Frame Advanced-grade composite, disc
Fork Advanced-grade composite, full-composite OverDrive 2 steerer, disc
Handlebar Giant Contact SL XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
Grips Stratus Lite 2.0
Stem Giant Contact SL XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
Seatpost Giant Variant, composite, -5/+15mm offset
Saddle Giant Fleet SL
Shifters Shimano 105 Di2
Front Derailleur Shimano 105 Di2
Rear Derailleur Shimano 105 Di2
Brakes Shimano 105 Di2 hydraulic, Shimano SM-RT70 rotors [F]160mm, [R]140mm
Brake Levers Shimano 105 Di2
Cassette Shimano 105, 12-speed, 11x34
Chain KMC X12L-1
Crankset Shimano 105, 36/52 with Giant Power Pro power meter XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket Shimano, press fit
Rims Giant SLR 1 36 Carbon Disc WheelSystem, [F] 36mm, [R] 36mm
Hubs [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Spokes Sapim CX-Ray
Tires Giant Gavia Course 1, tubeless, 700x25c (28mm), folding
Extras Computer mount, tubeless prepared, 32mm max tyre size
