*In-Store Collection Only*
*Description Coming Soon*
Size Guide
XS - 148 cm to 163 cm
S - 158 cm to 169 cm
M - 164 cm to 175 cm
L - 170 cm to 183 cm
| XS | S | M | L | ||
|---|---|---|---|---|---|
| SHORT | LONG | SHORT | LONG | SHORT | LONG | SHORT | LONG | ||
| A | SEAT TUBE LENGTH (mm) | 350 | 400 | 450 | 500 |
| B | SEAT TUBE ANGLE | 74.5° | 74.4° | 74.0° | 73.9° | 73.5° | 73.4° | 73.0° | 72.9° |
| C | TOP TUBE LENGTH (mm) | 525 | 525 | 540 | 540 | 560 | 560 | 580 | 580 |
| D | HEAD TUBE LENGTH (mm) | 110 | 135 | 165 | 195 |
| E | HEAD TUBE ANGLE | 70.5° | 70.5° | 71.0° | 71.0° | 71.5° | 71.5° | 71.5° | 71.5° |
| F | FORK RAKE (mm) | 50 | 50 | 50 | 50 |
| G | TRAIL (mm) | 73 | 75.3 | 69.5 | 71.9 | 66.2 | 68.6 | 66.2 | 68.6 |
| H | WHEELBASE (mm) | 1014 | 1023 | 1020 | 1030 | 1031 | 1041 | 1046 | 1056 |
| I | CHAIN STAY LENGTH (mm) | 425 | 435 | 425 | 435 | 425 | 435 | 425 | 435 |
| J | BOTTOM BRACKET DROP (mm) | 70 | 71 | 70 | 71 | 70 | 71 | 70 | 71 |
| K | STACK (mm) | 534 | 535 | 560 | 560 | 590 | 590 | 618 | 618 |
| L | REACH (mm) | 376 | 376 | 380 | 379 | 385 | 385 | 391 | 391 |
| M | STAND OVER HEIGHT (mm) | 680 | 680 | 710 | 710 | 745 | 745 | 770 | 770 |
| O | STEM LENGTH (mm) | 80 | 80 | 90 | 100 |
| P | CRANK LENGTH (mm) | 165 | 170 | 170 | 172.5 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C |
Specifications
Colours: Cordovan
Sizes: XS, S, M, L
Frame: Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout
Fork: Advanced-Grade Composite, full-composite OverDrive steerer, 12x100mm, disc
Shock: N/A
Handlebar: Giant Sport, flat
Grips: Giant ErgoContact
Stem: Giant Contact XS:80mm, S:80mm, M:90mm, L:100mm
Seatpost: Giant D-Fuse, composite
Saddle: Liv ErgoMax
Pedals: Platform pedal
Shifters: SRAM NX Eagle, 1x12
Front Derailleur: N/A
Rear Derailleur: SRAM Apex
Brakes: Shimano BR-U300, hydraulic [F]160mm, [R]160mm
Brake Levers: Shimano BL-MT201
Cassette: SRAM XPLR 1231, 11-44
Chain: SRAM Apex
Crankset: SRAM Apex, 42 XS:165mm, S:165mm, M:170mm, L:172.5mm
Bottom Bracket: SRAM DUB, press fit
Rims: Giant P-X2 Disc wheelset, alloy
Hubs: Giant alloy, 12mm thru-axle
Spokes: Stainless 14G
Tyres: Maxxis Re-Fuse, 700x40c, tubeless
Extras: 47mm max tyre size in long flip chip position, 42mm max tyre size in short flip chip position, tubeless prepared
Mfr Claimed Weight
TBC
