THIS COMPOSITE CHASSIS IS BUILT STRONG, LIGHT AND FAST FOR GIANT ENDURO PROS. A NEW SUSPENSION SETUP BEEN DEVELOPED, TESTED AND RACED AT THE HIGHEST LEVELS. AND MORE ADJUSTABILITY LETS YOU TACKLE TECHNICAL TRAILS JUST THE WAY YOU LIKE.
KEY PERFORMANCE FACTORS
Race-bred suspension
The Maestro rear suspension system with longer travel (160mm) was developed and tested under the extreme conditions of Enduro World Series races. The trunnion mount shock has a longer stroke (62.5mm compared to 60mm on the previous generation). And the Advanced Forged Composite upper rocker arm adds stiffness and lowers overall weight.
Adjustable enduro geometry
Flip chip technology lets you switch between three settings depending on the terrain. You can select a 63.5, 63.9 or 64.2-degree head angle and corresponding 78.3, 78.7 or 79-degree seat tube angle, resulting in a 35, 30 or 25mm bottom bracket drop (size medium) to fine-tune handling for trail conditions, riding style and rear-wheel size.
Rear wheel options
Riders can choose either a 29-or 27.5-inch rear wheel, paired with a 29-inch front wheel. The larger 29-inch option improves stability and roll-over capabilities, while the 27.5 option delivers a more agile, snappier feel. It’s a quick and easy change to adjust the bike’s handling and feel.
Frame Advanced-Grade Composite front and rear triangles, 160mm Maestro suspension, flip chip 3 position, 12x148mm thru-axle, 27.5 or 29-inch rear wheel compatible, integrated downtube storage, 55mm Chainline
Shock Fox DHX2 Factory, coil, 205/62.5, custom tuned for Giant S:425#, M:425#, L:450#, XL: 475#
Seatpost Seat clamp
Extras Rear 12x148mm thru-axle, seat clamp, maximum tyre size 2.6", maximum chainring size 34T
